Honda XL 750 Transalp (2023–2024) — Specs
Identity
Manufacturer: Honda
Model: XL 750 Transalp
Category: Adventure
Type: Motorcycle
Years: 2023 → 2024
Engine
Displacement (cc): 755
Cylinders: 2
Power (hp): 92
Power (kW): 68
Torque (Nm): 75
Dimensions
Overall length: 2325 mm
Overall width: 840 mm
Overall height: 1450 mm
Wheelbase: 1560 mm
Ground clearance: 210 mm
Weight (kg): 208
Seat height (mm): 850
Tank (L): 16.9
Tires
Front tire: 90/90-21
Rear tire: 150/70-18
Front pressure (bar): 2.3
Rear pressure (bar): 2.5
Drivetrain
Drive chain: 525 chain, 126 links
Sprockets (front / rear): 16 / 45
Ignition
Spark plug: NGK SILMAR8A9S
Plug gap: 0.8-0.9 mm
Fluids & Filters
Engine oil: SAE10W-30
Engine oil (with filter, L): 3.6
Engine oil (without filter, L): 3.4
Oil filter: Hiflofiltro HF204
Air filter: Hiflofiltro HFA1705
Coolant (L): 1.5
Brake fluid: DOT 4
Fuel consumption
Estimated range: ~375 km on a full tank (16.9 L)
Service
Battery: YTZ12S
Service interval (km): 10000
Service interval (months): 12
Valve check (km): 24000
Parts and consumables for this motorcycle
Data is gathered with care, but without guarantee. Always confirm critical information with your dealer or workshop.
Service notes
Service interval: every 10,000 km or 12 months, whichever comes first. Valve clearance check every 24,000 km. Engine oil: oil grade SAE10W-30, 3.6 L with filter change, 3.4 L without filter change. Spark plug: NGK SILMAR8A9S (gap 0.8-0.9 mm). Brake fluid: DOT 4. Coolant capacity: 1.5 L. Chain: 126 links, sprockets 16/45 teeth. Tire pressure: front 2.3 bar, rear 2.5 bar (cold). Tire size: front 90/90-21, rear 150/70-18. Always confirm critical values with the workshop manual or an authorised dealer.
OEM and quality aftermarket parts that fit this bike. Always confirm with your dealer before ordering.
Engine oil
Spec: SAE10W-30, 3.6 L (with filter), 3.4 L (without filter)
- OEM OEM recommended engine oil (SAE 10W-30)
- Premium Motul 7100 4T (100% Synthetic, Ester)
- Premium Motul 5100 4T Technosynthese (Semi-Synthetic)
Which Motul for this bike?
| Motul 7100 4T ✓ | Motul 5100 4T | |
|---|---|---|
| Product | Motul 7100 4T — 100% fully synthetic | Motul 5100 4T — semi-synthetic |
| Best for | Sport, Naked, Adventure (600cc+), track | Standard, Cruiser, Scooter, daily use |
| RPM protection | Excellent — ester base, stable under load | Good — for normal riding conditions |
- Standard Repsol Moto Racing 4T (Synthetic)
- Standard Elf Moto 4 Tech (Semi-Synthetic)
Fully Synthetic vs Semi-Synthetic
| Fully Synthetic | Semi-Synthetic | |
|---|---|---|
| Base oil | 100% chemical synthesis (ester or PAO) | Mineral oil + synthetic additives |
| Heat resistance | Excellent — stable at extreme heat & RPM | Good — suitable for normal temperatures |
| Cold start | Better — reaches engine faster when cold | Good — adequate for normal climates |
| Change interval | Longer (up to 10,000 km) | Shorter (5,000–7,000 km typical) |
| Price | Higher | Lower |
Oil filter
Spec: Hiflofiltro HF204
- Premium Hiflofiltro HF204
- Premium K&N KN-204
Air filter
Spec: Hiflofiltro HFA1705
- Standard Hiflofiltro HFA1705
Spark plug
Spec: NGK SILMAR8A9S, gap 0.8-0.9 mm
Front brake pads
Spec: OEM front pad (EBC equivalent: FA388HH)
- Premium EBC FA388HH
- Standard EBC FA388 (organic)
Rear brake pads
Spec: OEM rear pad (EBC equivalent: FA174HH)
- Premium EBC FA174HH
- Standard EBC FA174 (organic)
Drive chain
Spec: 126 links | Sprockets 16/45 teeth / 126 links
Front tire
Spec: 90/90-21, 2.3 bar
- OEM OEM 90/90-21
Rear tire
Spec: 150/70-18, 2.5 bar
- OEM OEM 150/70-18
Battery
Spec: OEM battery: Yuasa YTZ12S
- Premium Yuasa YTX14-BS or YTZ12S (typical 750-1000cc)
Brake fluid
Spec: DOT 4
- Standard TotalEnergies HBF4
Coolant
Spec: 1.50 L coolant capacity
Service interval
Spec: 10 000 km / 12 months
- OEM Engine oil + oil filter change
- OEM Air filter inspection
- OEM Spark plug check
- OEM Brake fluid replacement: every 2 years
Valve check
Spec: 24 000 km
Suspension
Spec: 43 mm USD fork
- OEM Fork: 43 mm USD fork
