Fantic CABALLERO 125 RALLY (EURO 4/5) (2019) — Specs
Identity
Manufacturer: Fantic
Model: CABALLERO 125 RALLY (EURO 4/5)
Category: Adventure
Type: Motorcycle
Years: 2019 →
Engine
Displacement (cc): 124
Cylinders: 1
Power (hp): 15
Power (kW): 11
Torque (Nm): 35
Dimensions
Overall length: 2270 mm
Overall width: 920 mm
Overall height: 1430 mm
Wheelbase: 1545 mm
Ground clearance: 220 mm
Weight (kg): 140
Seat height (mm): 860
Tank (L): 12
Tires
Front tire: 100/90-19
Rear tire: 130/80-17
Drivetrain
Drive chain: 428ER chain
Ignition
Spark plug: NGK CR8E
Plug gap: 0.8 mm
Fluids & Filters
Engine oil: SAE10W-40, API SG
Engine oil (with filter, L): 1
Engine oil (without filter, L): 0.95
Oil filter: Hiflofiltro HF691
Coolant (L): 1.5
Brake fluid: DOT 4 / DOT 5.1
Fuel consumption
Estimated range: ~342 km on a full tank (12.0 L)
Service
Service interval (km): 6000
Service interval (months): 12
Valve check (km): 12000
Parts and consumables for this motorcycle
Data is gathered with care, but without guarantee. Always confirm critical information with your dealer or workshop.
Service notes
Service interval: every 6,000 km or 12 months, whichever comes first. Valve clearance check every 12,000 km. Engine oil: oil grade SAE10W-40, API SG, 1 L with filter change, 0.95 L without filter change. Spark plug: NGK CR8E (gap 0.8 mm). Brake fluid: DOT 4 / DOT 5.1. Coolant capacity: 1.5 L. Chain: 428ER chain. Tire size: front 100/90-19, rear 130/80-17. Always confirm critical values with the workshop manual or an authorised dealer.
OEM and quality aftermarket parts that fit this bike. Always confirm with your dealer before ordering.
Engine oil
Spec: SAE10W-40, API SG, 1.0 L (with filter), 0.95 L (without filter)
- OEM OEM recommended engine oil (SAE 10W-40)
- Premium Motul 7100 4T (100% Synthetic, Ester)
Fully Synthetic vs Semi-Synthetic
| Fully Synthetic | Semi-Synthetic | |
|---|---|---|
| Base oil | 100% chemical synthesis (ester or PAO) | Mineral oil + synthetic additives |
| Heat resistance | Excellent — stable at extreme heat & RPM | Good — suitable for normal temperatures |
| Cold start | Better — reaches engine faster when cold | Good — adequate for normal climates |
| Change interval | Longer (up to 10,000 km) | Shorter (5,000–7,000 km typical) |
| Price | Higher | Lower |
Oil filter
Spec: Hiflofiltro HF691
- Premium Hiflofiltro HF691
Spark plug
Spec: NGK CR8E, gap 0.8 mm
- OEM NGK CR8E
- Premium NGK CR8EIX
Front brake pads
Rear brake pads
Front tire
Spec: 100/90-19
- OEM OEM 100/90-19
Rear tire
Spec: 130/80-17
- OEM OEM 130/80-17
Brake fluid
Spec: DOT 4 / DOT 5.1
Coolant
Spec: 1.50 L coolant capacity
Service interval
Spec: 6 000 km / 12 months
- OEM Engine oil + oil filter change
- OEM Air filter inspection
- OEM Spark plug check
- OEM Brake fluid replacement: every 2 years
Valve check
Spec: 12 000 km
Suspension
Spec: 41 mm USD fork / SAE 15W
- OEM Fork: 41 mm USD fork
- OEM Fork oil grade: SAE 15W
Air filter
Drive chain
Battery
- Premium Yuasa YTX5L-BS or YT4B-BS (typical 50-125cc)
