Kreidler MUSTANG 200 (2005) — Specs
Identity
Manufacturer: Kreidler
Model: MUSTANG 200
Category: ATV/Quad
Type: ATV/Quad
Years: 2005 →
Engine
Displacement (cc): 199
Cylinders: 1
Power (hp): 16
Power (kW): 12
Torque (Nm): 5
Dimensions
Overall length: 1950 mm
Overall width: 720 mm
Overall height: 1110 mm
Wheelbase: 1340 mm
Ground clearance: 150 mm
Weight (kg): 175
Tank (L): 8
Tires
Front pressure (bar): 0.8
Rear pressure (bar): 0.8
Drivetrain
Drive chain: 428 chain, 95 links
Sprockets (front / rear): 14 / 40
Ignition
Spark plug: NGK DR8EA
Plug gap: 0.7 mm
Fluids & Filters
Engine oil: SAE15W-40
Engine oil (with filter, L): 1.2
Engine oil (without filter, L): 1.1
Oil filter: OEM oil filter
Brake fluid: DOT 4
Fuel consumption
Estimated fuel consumption: ~3.0 L/100 km
Estimated range: ~266 km on a full tank (8.0 L)
Note: estimate based on engine size + bike type. Real-world ±20%.
Service
Service interval (km): 6000
Service interval (months): 12
Valve check (km): 12000
Parts and consumables for this motorcycle
Data is gathered with care, but without guarantee. Always confirm critical information with your dealer or workshop.
Service notes
Service interval: every 6,000 km or 12 months, whichever comes first. Valve clearance check every 12,000 km. Valve clearance — intake cold 0.03 mm, exhaust cold 0.03 mm. Engine oil: oil grade SAE15W-40, 1.2 L with filter change, 1.1 L without filter change. Spark plug: NGK DR8EA (gap 0.7 mm). Brake fluid: DOT 4. Chain: 95 links, sprockets 14/40 teeth. Tire pressure: front 0.8 bar, rear 0.8 bar (cold). Always confirm critical values with the workshop manual or an authorised dealer.
OEM and quality aftermarket parts that fit this bike. Always confirm with your dealer before ordering.
Engine oil
Spec: SAE15W-40, 1.2 L (with filter), 1.1 L (without filter)
- OEM OEM recommended engine oil (SAE 15W-40)
- Premium Motul 7100
Fully Synthetic vs Semi-Synthetic
| Fully Synthetic | Semi-Synthetic | |
|---|---|---|
| Base oil | 100% chemical synthesis (ester or PAO) | Mineral oil + synthetic additives |
| Heat resistance | Excellent — stable at extreme heat & RPM | Good — suitable for normal temperatures |
| Cold start | Better — reaches engine faster when cold | Good — adequate for normal climates |
| Change interval | Longer (up to 10,000 km) | Shorter (5,000–7,000 km typical) |
| Price | Higher | Lower |
Oil filter
Spark plug
Spec: NGK DR8EA, gap 0.7 mm
- OEM NGK DR8EA
- Premium NGK DR8EIX
Front brake pads
Rear brake pads
Front tire
Spec: 0.8 bar
Rear tire
Spec: 0.8 bar
Brake fluid
Spec: DOT 4
Coolant
Service interval
Spec: 6 000 km / 12 months
- OEM Engine oil + oil filter change
- OEM Air filter inspection
- OEM Spark plug check
- OEM Brake fluid replacement: every 2 years
Valve check
Spec: 12 000 km
- OEM Intake clearance: cold 0.03 mm
- OEM Exhaust clearance: cold 0.03 mm
Air filter
Drive chain
Battery
- Premium Yuasa YTX7L-BS or YTX7A-BS (typical 125-250cc)
