Honda CRF 150 RB 19/16 ZOLL (2016) — Specs
Identity
Manufacturer: Honda
Model: CRF 150 RB 19/16 ZOLL
Category: Off-Road Bike
Type: Off-Road Bike
Years: 2016 → 2016
Engine
Displacement (cc): 150
Cylinders: 1
Power (hp): 24
Power (kW): 18
Torque (Nm): 12.4
Dimensions
Overall length: 1950 mm
Overall width: 720 mm
Overall height: 1110 mm
Wheelbase: 1340 mm
Ground clearance: 150 mm
Weight (kg): 84
Seat height (mm): 866
Tires
Front tire: 70/100-19
Rear tire: 90/100-16
Front pressure (bar): 1
Rear pressure (bar): 1
Drivetrain
Drive chain: 126 links 420
Sprockets (front / rear): 15 / 53
Ignition
Spark plug: NGK CR8EH-9
Plug gap: 0.8-0.9 mm
Fluids & Filters
Engine oil: SAE10W-30, API SG
Engine oil (with filter, L): 0.57
Oil filter: Hiflofiltro HF116
Air filter: Hiflofiltro HFA1209
Coolant (L): 0.8
Brake fluid: DOT 4
Service
Battery: YTX4L-BS
Service interval (km): 6000
Service interval (months): 12
Valve check (km): 12000
Parts and consumables for this motorcycle
Data is gathered with care, but without guarantee. Always confirm critical information with your dealer or workshop.
Service notes
Service interval: every 6,000 km or 12 months, whichever comes first. Valve clearance check every 12,000 km. Valve clearance — intake cold 0.13-0.19 mm, exhaust cold 0.23-0.29 mm. Engine oil: oil grade SAE10W-30, API SG, 0.57 L with filter change. Spark plug: NGK CR8EH-9 (gap 0.8-0.9 mm). Brake fluid: DOT 4. Coolant capacity: 0.8 L. Chain: 126 links 420, sprockets 15/53 teeth. Tire pressure: front 1 bar, rear 1 bar (cold). Tire size: front 70/100-19, rear 90/100-16. Always confirm critical values with the workshop manual or an authorised dealer.
OEM and quality aftermarket parts that fit this bike. Always confirm with your dealer before ordering.
Engine oil
Spec: SAE10W-30, API SG, 0.57 L (with filter)
- OEM OEM recommended engine oil (SAE 10W-30)
- Premium Motul 7100 4T (100% Synthetic, Ester)
- Premium Motul 5100 4T Technosynthese (Semi-Synthetic)
Which Motul for this bike?
| Motul 7100 4T ✓ | Motul 5100 4T | |
|---|---|---|
| Product | Motul 7100 4T — 100% fully synthetic | Motul 5100 4T — semi-synthetic |
| Best for | Sport, Naked, Adventure (600cc+), track | Standard, Cruiser, Scooter, daily use |
| RPM protection | Excellent — ester base, stable under load | Good — for normal riding conditions |
- Standard Repsol Moto Racing 4T (Synthetic)
- Standard Elf Moto 4 Tech (Semi-Synthetic)
Fully Synthetic vs Semi-Synthetic
| Fully Synthetic | Semi-Synthetic | |
|---|---|---|
| Base oil | 100% chemical synthesis (ester or PAO) | Mineral oil + synthetic additives |
| Heat resistance | Excellent — stable at extreme heat & RPM | Good — suitable for normal temperatures |
| Cold start | Better — reaches engine faster when cold | Good — adequate for normal climates |
| Change interval | Longer (up to 10,000 km) | Shorter (5,000–7,000 km typical) |
| Price | Higher | Lower |
Oil filter
Spec: Hiflofiltro HF116
- Premium Hiflofiltro HF116
- Premium K&N KN-116
Air filter
Spec: Hiflofiltro HFA1209
- Standard Hiflofiltro HFA1209
Spark plug
Spec: NGK CR8EH-9, gap 0.8-0.9 mm
- OEM NGK CR8EH-9
- Premium NGK CR8EHIX-9
- Standard NGK CR8EH-9
Front brake pads
Spec: OEM front pad (EBC equivalent: FA185HH)
- Premium EBC FA185HH
- Standard EBC FA185 (organic)
Rear brake pads
Spec: OEM rear pad (EBC equivalent: FA208HH)
- Premium EBC FA208HH
- Standard EBC FA208 (organic)
Drive chain
Spec: 126 links 420 | Sprockets 15/53 teeth / 126 links 420
Front tire
Spec: 70/100-19, 1.0 bar
- OEM OEM 70/100-19
Rear tire
Spec: 90/100-16, 1.0 bar
- OEM OEM 90/100-16
Battery
Spec: OEM battery: Yuasa YTX4L-BS
- Premium Yuasa YTX7L-BS or YTX7A-BS (typical 125-250cc)
Brake fluid
Spec: DOT 4
- Standard TotalEnergies HBF4
Coolant
Spec: 0.80 L coolant capacity
Service interval
Spec: 6 000 km / 12 months
- OEM Engine oil + oil filter change
- OEM Air filter inspection
- OEM Spark plug check
- OEM Brake fluid replacement: every 2 years
Valve check
Spec: 12 000 km
- OEM Intake clearance: cold 0.13-0.19 mm
- OEM Exhaust clearance: cold 0.23-0.29 mm
Suspension
Spec: 37 mm USD fork / 342 ml SAE 5W
- OEM Fork: 37 mm USD fork
- OEM Fork oil grade: 342 ml SAE 5W
